Why Parquet Structure Matters for Fast Queries

☕ If you think you already know this, feel free to scroll down. There is a summary table at the end, followed by useful references for you—or your LLM.

Otherwise, let's start with a simple coffee business and follow the bytes.

Part I — Why Columnar Storage Is Fast

1. From Coffee Sales to Business Questions

Imagine a coffee-shop network similar to Starbucks.

Over the last three years, the network collected about 100 GB of sales data. Every transaction produces a row describing what was sold, where it was sold, when it happened, and for how much.

The original data could look like a CSV file:

timestamp,branch_id,city,product,flavor,size,quantity,unit_price,payment_type,customer_id
2026-07-14 08:13:21,BR017,London,Latte,Vanilla,Large,2,5.20,Card,C839201
2026-07-14 08:14:03,BR042,Manchester,Espresso,Classic,Single,1,2.80,Cash,C104833
2026-07-14 08:14:18,BR017,London,Cold Brew,Caramel,Medium,1,4.90,App,C550182

There are 10 columns, and in the real file there may be hundreds of thousands or millions of rows.

The interesting question is:

How do we search through it quickly enough to turn it into useful business information?

What the Business Wants to Know

A manager does not want to look at transaction rows.

They want a dashboard.

Coffee Network — July Dashboard

Behind each number is a query.

For example:

SELECT
    SUM(quantity * unit_price) AS revenue
FROM sales
WHERE timestamp >= '2026-07-01'
  AND timestamp < '2026-08-01';

Or:

SELECT
    flavor,
    SUM(quantity) AS cups
FROM sales
WHERE timestamp >= '2026-07-01'
  AND timestamp < '2026-08-01'
GROUP BY flavor
ORDER BY cups DESC
LIMIT 1;

These queries look simple.

But underneath them is the main subject of this paper:

What data does the computer actually have to scan in order to answer the query?

2. Scan Less, Query Faster

Consider the monthly revenue query:

SELECT
    SUM(quantity * unit_price)
FROM sales
WHERE timestamp >= '2026-07-01'
  AND timestamp < '2026-08-01';

Our dataset has 10 columns, but this query needs only three:

timestamp
quantity
unit_price

The other seven columns are irrelevant.

If the data is stored as ordinary CSV rows, we keep encountering information the query does not need.

Query performance is often less about processing data faster and more about scanning less data in the first place.

Why Scanning Less Matters

Data must physically move before the CPU can process it.

These are illustrative numbers rather than guarantees.

Object Store / Network
          ↓
         SSD
          ↓
        Memory
          ↓
         CPU

If a query needs only 1GB of useful information from a 100 GB dataset, scanning all 100 GB and throwing away 99GB is work that ideally should never happen.

3. Why Columnar Storage Is Fast

From Rows to Columns

CSV is organized by rows:

08:13 | BR17 | London | Latte    | Vanilla | Large  | 2 | 5.20 | Card | C839201
08:14 | BR42 | Leeds  | Espresso | Classic | Single | 1 | 2.80 | Cash | C104833
08:14 | BR17 | London | ColdBrew | Caramel | Medium | 1 | 4.90 | App  | C550182

Analytical queries frequently use only a few columns.

Columnar storage organizes values by column, so our revenue query can scan only:

timestamp
quantity
unit_price

instead of all ten columns.

Binary Instead of Text

Columnar formats also do not need to store values as human-readable text.

Timestamps, integers, and prices can be stored as compact typed binary values that are closer to what the CPU needs for comparisons and calculations.

Columns Compress Extremely Well

Values within one column tend to resemble each other:

branch_id:
BR017
BR017
BR017
BR042
...

flavor:
Vanilla
Vanilla
Caramel
Vanilla
...

That repetition makes column encoding and compression effective.

Real columnar formats use techniques such as dictionary encoding, run-length encoding, bit packing, delta encoding, and compression algorithms.

                    Columnar storage
                          │
          ┌───────────────┼────────────────┐
          ↓               ↓                ↓
   fewer columns       binary data      compression
          │               │                │
          └───────────────┴────────────────┘
                          ↓
                  fewer bytes scanned
                          ↓
                    faster queries

Part II — Skipping Rows with Parquet Structure

4. The Cost of Scanning Too Much

Suppose 80% of the dashboard queries are about today or yesterday.

But our Parquet file contains three years of sales.

One day is only:

1 / (3 × 365) ≈ 0.09%

of the data.

So the hottest part of our dataset is tiny:

3 years of data
│
├─ HOT   0.09%  ▏ today / yesterday
├─ WARM  ~2%    ██ recent weeks
└─ COLD  ~98%   ███████████████████████████████████████████████

80% of our queries may care about less than 1% of our data.

Sorting by timestamp helps organize the data, but a Parquet scan does not behave like a database B-tree index. Sorting alone does not give us direct row access.

We need large physical regions of the file to be independently skippable.

5. Partitioning the Data by Time

One solution is separate files:

sales/
    2026-08-24.parquet
    2026-08-25.parquet
    2026-08-26.parquet
    2026-08-27.parquet

But a partition does not have to be a separate file.

Parquet already contains an internal partition-like structure: the row group (RG).

sales.parquet

RG → 2026-08-24
RG → 2026-08-25
RG → 2026-08-26
RG → 2026-08-27
...

Now each day is independently skippable.

For three years of data:

Query         Data scanned

3 years       ████████████████████████████████████  100%
1 year        ████████████                           ~33%   → 3× less
1 month       █                                      ~2.7%  → 36× less
1 week        ▏                                      ~0.6%  → 156× less
1 day         ▏                                      ~0.09% → 1,095× less

The key idea is:

one day = one independently skippable physical batch

That batch can be a file, but it can also be a row group inside a larger Parquet file.

6. How Parquet Knows Which Row Groups to Skip

If yesterday is one row group inside a large Parquet file, how can the query engine find it without scanning all the others?

The answer is the Parquet footer.

┌─────────────────────────────────────┐
│ Row Group 1                         │
├─────────────────────────────────────┤
│ Row Group 2                         │
├─────────────────────────────────────┤
│ Row Group 3                         │
├─────────────────────────────────────┤
│ Footer                              │
└─────────────────────────────────────┘

For our purpose, two pieces of footer information are especially important:

• min/max values for columns inside row groups
• physical locations of column chunks in the file

For example:

RG 1
    timestamp.min = 2026-08-24 00:00
    timestamp.max = 2026-08-24 23:59

RG 2
    timestamp.min = 2026-08-25 00:00
    timestamp.max = 2026-08-25 23:59

RG 3
    timestamp.min = 2026-08-26 00:00
    timestamp.max = 2026-08-26 23:59

For:

WHERE timestamp >= '2026-08-26'
  AND timestamp < '2026-08-27'

the engine can reason:

RG 1  Aug 24  → skip
RG 2  Aug 25  → skip
RG 3  Aug 26  → READ
RG 4  Aug 27  → skip

The engine does not need to scan the timestamp values in RG 1 and RG 2 to discover that they are irrelevant.

The footer does not create the organization. It exposes the organization we created so the query engine can avoid scanning data.

7. The DayMonthQuarterYear Pattern

Daily row groups solve the hot-data problem, but keeping the entire history as daily row groups is unnecessarily fine-grained.

A query-oriented layout can use progressively larger periods:

RG → today
RG → yesterday

RG → previous 30 days
RG → previous 30 days

RG → previous 90 days
RG → previous 90 days
RG → previous 90 days
RG → previous 90 days
RG → previous 90 days

RG → previous 360 days
RG → previous 360 days
...

Approximately:

Day | Day | Month | Month | Q | Q | Q | Q | Q | Year | Year | ...

This is the DayMonthQuarterYear pattern.

The layout changes every day, so we maintain it using two layers.

The first is an immutable daily base:

daily/
    2026-08-24.parquet
    2026-08-25.parquet
    2026-08-26.parquet
    2026-08-27.parquet
    ...

The second is a query-optimized Parquet layout built incrementally from that base:

stable daily data
       ↓
incremental ETL
       ↓
Day | Day | Month | Month | Q | Q | Q | Q | Q | Year | ...
       ↓
fast scans

As data ages:

Day → Month → Quarter → Year

Most historical row groups remain unchanged and can be reused.

Store the data at a stable daily grain, then incrementally build the Parquet row-group layout that best matches how users query it today.

Part III — Parquet on Object Storage

8. Object Storage Changes the Storage Model

The original Parquet recommendations were strongly influenced by HDFS and large sequential disk reads.

Compute
   ↑
HDFS
   ↑
attached disks

Modern cloud analytics often uses:

       Parquet
          │
          ↓
   Object Storage
      S3 / GCS
          │
    ┌─────┼─────┐
    ↓     ↓     ↓
 Lambda DuckDB Trino

The storage is independent of the compute.

The Parquet files can remain permanently in object storage while compute is started only when needed.

Assume a small HDFS cluster using inexpensive cloud machines and disks, approximately 3× replication, and relatively few queries.

Using intentionally rounded numbers:

HDFS has a significant fixed cost because storage lives on running DataNodes.

Object storage is closer to paying for bytes stored independently of compute.

The next question is:

If the Parquet file is remote, how much of it actually needs to cross the network?

9. Column Size Matters

Our coffee table is already aggregated.

Each row represents:

one minute × one branch × one product

For example:

{"minute":"08:13","branch":"B17","product":"Latte","quantity":17,"employee_ids":["E42","E19"],"customer_ids":["C839201","C104833","C550182"]}
{"minute":"08:13","branch":"B17","product":"Espresso","quantity":8,"employee_ids":["E42"],"customer_ids":["C772192","C441927"]}

These fields behave very differently:

product
    → hundreds of possible values
    → repeats heavily

employee_ids[]
    → thousands of possible values
    → some repetition

customer_ids[]
    → millions of possible values
    → high cardinality

Parquet stores these as separate columnar leaf streams. The details of repeated arrays are covered in Appendix A.

The important result is that their compressed sizes can be very different.

             SAME LOGICAL DATASET

product       █
quantity      █
employee_ids  █████
customer_ids  ███████████████████

The bars are conceptual, not measured sizes.

For:

SELECT
    product,
    SUM(quantity)
FROM coffee_sales
GROUP BY product;

the reader needs:

product       → READ
quantity      → READ

employee_ids  → SKIP
customer_ids  → SKIP

Even if customer_ids is the largest column in the file, zero customer-ID data needs to cross the network for this query.

So when Parquet lives in S3 or GCS, the important quantity is:

bytes fetched
     =
footer / metadata
     +
compressed size of needed columns
inside needed row groups

not the complete row-group size.

                    PARQUET
                       │
            ┌──────────┴──────────┐
            ↓                     ↓
         ROW GROUPS             COLUMNS
            │                     │
       Which rows?           Which fields?
            │                     │
            └──────────┬──────────┘
                       ↓
              bytes over network

For object-store Parquet, we care about the size of the columns the query actually needs—not the size of the complete row group.

10. What We Learned

The important question is not how quickly we can scan our Parquet file. It is how we can structure the file so that most of it never needs to be scanned.

References

1. Amazon Athena Documentation https://docs.aws.amazon.com/athena/ A direct industry example of the architecture discussed in Part III: Athena is serverless and queries data directly in S3 using SQL, without requiring a persistent query cluster.

2. Apache Parquet — Nested Encoding https://parquet.apache.org/docs/file-format/nestedencoding/ Explains Parquet's Dremel-based representation of repeated and optional nested values using repetition and definition levels.

3. DuckDB — Parquet Overview https://duckdb.org/docs/stable/data/parquet/overview Practical example of an analytical engine reading and writing Parquet and pushing projections and filters into the Parquet scan.

4. DuckDB — Parquet Tips https://duckdb.org/docs/stable/data/parquet/tips Discusses row groups, parallelism, sorting, and using Parquet statistics for row-group pruning.

Appendix A — How Parquet Stores Repeated Values

Consider three logical rows:

{"product":"Latte","quantity":17,"employee_ids":["E42","E19"]}
{"product":"Espresso","quantity":8,"employee_ids":["E42"]}
{"product":"Latte","quantity":12,"employee_ids":["E42","E19"]}

Conceptually:

employee_ids

E42 | E19 || E42 || E42 | E19
          ↑      ↑
       new row  new row

Parquet does not literally store | and || characters. It stores compact repetition levels alongside the values.
